B50I-RGF Impact Crusher with Roller Grizzly Feeder

With a 1270mm (50″) x 915mm (36″) impactor (the widest impactor in its class), the B50I places Böhringer Group at the forefront of track portable crushing systems. Maximum productivity is delivered through the enhancements to the impactor with heavy duty closed rotor enhancement for all crushing applications. Placed before the impactor, the B50I’s RGF provides greater reduction and the fastest material throughput on the market, by offering greater separation of fines prior to the material overs entering the crusher chamber.

The B50I-RG crusher brings more production, more power and greater fuel efficiency thanks to the Cat® C13B at its core. Breaking boundaries is in Böhringer’s DNA and the B50I-RGF is a reflection of 76 years of design innovation, coupled with industry leading modern appointments and unmatched output capacity.


Heavy duty track mounted crusher with the following features:

  • 1270mm (50”) Size X9.15m (50”X 36”) Impact Crusher.
  • 402 kw- 540Hp Cat C15ATAAC diesel engine.
  • Track: 800mm 31.5” shoes.
  • Integrated fixed hopper Over 20” 6.000m RGF
  • Integrated Stockpiling conveyors. With Optional Combi- link stacker link.
  • RHS-beam – plate fabricated chassis construction.
  • Optimal space between crusher discharge and main conveyor feed boot.
  • Open chassis design for ease of maintenance.
  • Fast setup time.

Operating Dimensions

Length – working all models 18.90m (62′)
Length – transport all models 4.1m (13′ – 5″)
Height  – transport track 18.90m (62′)
Weight – track (kgs) 83,345 kgs
Weight – track (lbs) 182,983 lbs
